You have configured your SharePoint Outgoing Email but even the configuration correct you could not able to send emails from SharePoint.
For more information about how to configure outgoing emails on SharePoint please check following article:
So what you can do;
First Check the ULS Logs ; You may facing following error;
Failed attempt 1 sending mail to recipients: email@example.com . Mail Subject: System Account has invited you “Blog Members”.
Error: SmtpException while sending
email: System.Net.Mail.SmtpException: The SMTP server requires a secure connection or the client was not authenticated. The server response was: 5.7.1
Client was not authenticated
at System.Net.Mail.MailCommand.CheckResponse(SmtpStatusCode statusCode,
String response) at
MailAddressCollection recipients, String deliveryNotify, Boolean allowUnicode,
Usually this problem not caused by SharePoint it self, It is happening when SharePoint connects to Exchange server but Exchange is not authorize SharePoint to send emails. Why ? Because by design SharePoint use anonymous authentication to connect Exchange and OOB you can not configure SharePoint for any other authentication for using SMTP emails . If the recieve connector of the Exchange will require authentication that would be the problem .
You can test your stmp server by telnet client for anonymous authentication. or may collect Network Monitor logs that what is the communication and what is the authentication when SharePoint is trying to send emails.
For Telnet test;
1) Start a command prompt with administrator priviledges.
2) type following command:
telnet <Your SMTP server IP> 25
250-AUTH NTLM ***** Server requires NTLM .
In network trace you can detect as
Frame: Number = 1087, Captured Frame Length = 316, MediaType = ETHERNET
+ Ethernet: Etype = Internet IP (IPv4),DestinationAddress:[00-50-56-B3-16-5A],SourceAddress:[38-22-D6-D4-49-80]
+ Ipv4: Src = 10.10.100.20, Dest = 10.20.100.59, Next Protocol = TCP, Packet ID = 9437, Total IP Length = 302
+ Tcp: Flags=…AP…, SrcPort=SMTP(25), DstPort=46805, PayloadLen=262, Seq=41429760 – 41430022, Ack=1350847993, Win=256 (scale factor 0x8) = 65536
– Smtp: Rsp 250 -<server> Hello [10.20.100.59], 262 bytes
– Response: 250 -<server> Hello [10.20.100.59]
ReplyCode: 250, OK, queuing for node node started, or Requested mail action okay, completed
+ ReplyMessage: -<server> Hello [10.20.100.59] —-> Sharepoint opens session with 10.20.100.59
ReplyMessage: 250-AUTH NTLM —-> Exchange providing NTLM.
ReplyMessage: 250-X-EXPS GSSAPI NTLM
ReplyMessage: 250 XSHADOW
1) Giving SharePoint Computer account mail submit priviledges
2) Creating a new Recieve Connector on Exchange for SharePoint and provide only anonymous auth.
